Details
°Technical Features
- 20-Year Design Life
- Cycle life in excess of 1200 cycles to 80% DOD
- Flame Retardant ABS Cover and Container, UL94 V-0, LOI>28%
- Patented copper alloy terminal design
- 6 months of storage at 77°F (25°C) with a capacity 86%
- Initial capacity at 100%
- Low pressure flame arresting valve(s) UL1989
- Absorbent Glass Mat (AGM) Sealed Technology,
- Recombination efficiency of 99.9%
Compliance and Safety:
- ISO 9001:2000 and ISO 14001:2004 certified production facilities
- UL Recognized Component 924, for use in or width
listed UL1778, UL1989 and UL924 systems - IEC60896-21/22 / BS6290 part 4
- Certified to NEBS Version 4, Level 3
- Telcordia GR-1089-CORE, Issue 4
- Telcordia GR-63-CORE, Issue 4
- Compliant to SR-4228 & VZ.TPR.9802
- Manufactured under system ISO9001(TUV)
- Battery installation compliant with: EN 50272-2 or local equivalents
- NEBS Earthquake Risk Seismic Zone 4 Compliant
- Exceeds 1997 UBC Zone 4 Seismic requirements for at or below
grade installations / Exceeds 2007 IBC requirements for 125% g level
Transportation:
- Classified as Nonspillable UN 2800 and meet the Nonspillable criteria listed in
DOT-CFR Title 49, 171-189 (d) (3) (i) and (ii) and exempt from CFR 49, Subchapter C requirements - Meets transportation conditions of IMDG exemption 238, IATA/ICAO Special Provision A67 (Not Restricted)
